How to Choose a Utility or Cargo Trailer

A good utility trailer carries building materials, equipment, garden waste and farm loads for years. These are the points that decide whether it suits you.

What you will carry

Start with your typical load and your longest item. That decides the length and the weight rating.

Size

  • 2 metres: 2450 x 1120 mm bin with 1000 mm sides, for lighter loads behind a car or bakkie.
  • 3 metres: 3000 x 1500 mm bin with 1200 mm sides, the all rounder.
  • 4 metres: 4000 x 1800 mm bin with 1200 mm sides on a 100 x 50 mm chassis, for long or bulky loads.

Weight rating and brakes

The rating, or gross vehicle mass, is the most the trailer and load may weigh together. Unbraked trailers are rated at 750 kg. For more, choose a braked trailer with 45 mm square axles rated at 1500 kg each.

Single or double axle

A single braked axle gives 1500 kg. A double axle gives 3000 kg, spreads the load and tows more steadily, with a 3 ton braked coupler with damper.

Check the build

Look for a heavy duty U channel steel chassis, a 2.5 mm hot rolled steel floor, and a frame and drop sides in 50 x 50 mm steel.

Road legal from the start

Halogen lights, a 7 pin plug, reflectors, a chevron board and reflective tape along both sides.

Useful extras

Mesh sides, loading ramps, spare wheel brackets, tie down rails, ladder racks, lockable toolboxes and winches can all be added.

See the range

Compare every size in cargo trailers, or contact your nearest branch for a quote.
