5 Meter Heavy-Duty Animal Trailer – 3000kg GVM Tandem Axle Braked Livestock Trailer

Our 5 Meter Heavy-Duty Animal Trailer is built for farmers, game breeders, agricultural contractors, and commercial livestock operators who require a spacious, durable, and dependable trailer for transporting animals safely. Designed to withstand demanding farming conditions, this 3000kg GVM tandem axle livestock trailer offers excellent load capacity, towing stability, and long service life.

Manufactured from high-quality steel and fitted with a twin braked axle system, this trailer provides safe and controlled towing while accommodating larger numbers of sheep, goats, pigs, calves, cattle, and other livestock.

Features

• Overall Dimensions: 5.0 m (L) × 1.8 m (W) × 2.2 m (H)
• 3000 kg Gross Vehicle Mass (GVM)
• Heavy-duty 75 x 38 mm U-channel chassis
• 50 x 50 mm square tubing frame for exceptional structural strength
• Twin 46 mm square braked axles
• Tandem axle configuration
• 3000 kg carrying capacity
• 14-inch wheels and tyres
• Heavy-duty 60 mm round double jockey wheel
• 3-ton braked cast iron galvanised trailer coupler with hydraulic damper
• Combination 4-in-1 rear lighting including brake, tail, indicator, and number plate light
• Standard 7-pin trailer plug
• Red 50 mm front mudguard reflectors
• White 50 mm rear mudguard reflectors
• Standard 1150 mm rear chevron board
• 50 mm yellow reflective tape covering approximately 70% of both trailer sides for increased road visibility
• Heavy-duty mudguards (not designed as standing platforms)

Ideal Applications

• Cattle transport
• Sheep transport
• Goat transport
• Pig transport
• Calf transport
• Livestock transport
• Game farm animal transport
• Commercial farming operations
• Agricultural businesses
• Smallholdings and ranches

The 5 meter tandem axle livestock trailer is engineered to deliver outstanding strength, safety, and reliability for professional animal transport. Its extended loading area, heavy-duty construction, premium braking system, and quality towing components make it the ideal solution for moving livestock efficiently and safely throughout South Africa.

Please Note: Trailer supplied in standard specification with no additional optional equipment unless otherwise specified.
